TSZU52 Series

Catalog

603, 150MW, 5%, SMALL SIGNAL ZEN

Part	Impedance (Max) (Zzt) [Max]	Voltage - Forward (Vf) (Max) @ If [Max]	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Package / Case	Voltage - Zener (Nom) (Vz)	Power - Max [Max]	Mounting Type	Current - Reverse Leakage @ Vr
Taiwan Semiconductor Corporation TSZU52C2V2	100 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	2.2 V	150 mW	Surface Mount	100 µA
Taiwan Semiconductor Corporation TSZU52C15 RGG	30 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	15 V	150 mW	Surface Mount	100 nA
Taiwan Semiconductor Corporation TSZU52C16 RGG	40 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	16 V	150 mW	Surface Mount	100 nA
Taiwan Semiconductor Corporation TSZU52C3V9	95 Ohms	0.9 V	4.99 %	-55 ░C	125 °C	1608 Metric	0603	3.9 V	150 mW	Surface Mount	10 µA
Taiwan Semiconductor Corporation TSZU52C3V6	95 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	3.6 V	150 mW	Surface Mount	15 µA
Taiwan Semiconductor Corporation TSZU52C2V2 RGG	100 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	2.2 V	150 mW	Surface Mount	100 µA
Taiwan Semiconductor Corporation TSZU52C13	25 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	13 V	150 mW	Surface Mount	100 nA
Taiwan Semiconductor Corporation TSZU52C3V0 RGG	95 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	3 V	150 mW	Surface Mount	50 µA
Taiwan Semiconductor Corporation TSZU52C12 RGG	20 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	12 V	150 mW	Surface Mount	100 nA
Taiwan Semiconductor Corporation TSZU52C6V2	10 Ohms	0.9 V	5 %	-55 ░C	125 °C	1608 Metric	0603	6.2 V	150 mW	Surface Mount	100 nA
