892-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 27POS 0.100
| Part | Termination Rows | Material - Insulation | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Read Out | Color | Contact Finish | Pitch | Pitch | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Card Thickness [Max] | Card Thickness [Min] | Gender | Number of Positions/Bay/Row | Contact Type | Number of Rows | Number of Positions | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Right Angle Through Hole |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Single Edge | Single | Black | Gold | 0.1 " | 2.54 mm | Copper Alloy | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 27 | Cantilever | 1 | 27 | Through Hole |
