74LVC2G04 Series

Catalog

IC INVERTER DUAL

Part	Supplier Device Package [y]	Supplier Device Package [x]	Supplier Device Package	Voltage - Supply [Max]	Voltage - Supply [Min]	Number of Circuits	Logic Type	Package / Case	Mounting Type	Input Logic Level - Low [Max]	Input Logic Level - Low [Min]	Current - Quiescent (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Output High, Low [y]	Current - Output High, Low [x]	Max Propagation Delay @ V, Max CL	Number of Inputs	Input Logic Level - High [Min]	Input Logic Level - High [Max]
Freescale Semiconductor - NXP 74LVC2G04GXZ	0.8	1	6-X2SON	5.5 V	1.65 V	2	Inverter	6-XFDFN Exposed Pad	Surface Mount	0.8 V	0.7 V	4 µA	125 °C	-40 °C	32 mA	32 mA	3.8 ns	2	1.7 V	2 V
Freescale Semiconductor - NXP 74LVC2G04GF,132			6-XSON (1x1)	5.5 V	1.65 V	2	Inverter	6-XFDFN	Surface Mount	0.8 V	0.7 V	4 µA	125 °C	-40 °C	32 mA	32 mA	3.2 ns	2	1.7 V	2 V
