IP425 Series

Catalog

FILTER RC(PI) 40 OHM/12PF SMD

Part	Values	Filter Order	Applications	Technology	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Package / Case	Number of Channels	Resistance - Channel (Ohms)	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Type	Height [z]	Height [z]	Attenuation Value	Number of Channels [custom]
Freescale Semiconductor - NXP IP4252CZ8-4,118	12 pF 40 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.067 in	1.7 mm	8-XFDFN Exposed Pad	4	40 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	12 dB
Freescale Semiconductor - NXP IP4253CZ16-8,118	30 pF 200 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.13 in	3.3 mm	16-XFDFN Exposed Pad	8	200 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	33 dB
Freescale Semiconductor - NXP IP4252CZ16-8,118	12 pF 40 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.13 in	3.3 mm	16-XFDFN Exposed Pad	8	40 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	12 dB
Freescale Semiconductor - NXP IP4253CZ12-6,118	30 pF 200 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.098 "	2.5 mm	12-XFDFN Exposed Pad		200 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	33 dB	6
Freescale Semiconductor - NXP IP4251CZ16-8,118	10 pF 100 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.13 in	3.3 mm	16-XFDFN Exposed Pad	8	100 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	16 dB
Freescale Semiconductor - NXP IP4251CZ8-4,118	10 pF 100 Ohms	2nd	LAN WAN	RC (Pi)	1.35 mm	0.053 in	0.067 in	1.7 mm	8-XFDFN Exposed Pad	4	100 Ohms	Surface Mount	85 °C	-40 °C	Low Pass	0.02 in	0.5 mm	16 dB
