415-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE METAL TO METAL 2 PIECE CONNECTORS
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Features | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness | Card Thickness | Number of Rows [custom] | Gender | Card Type | Color | Mounting Type | Contact Finish | Termination | Note | Material Flammability Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | -65 ░C | 125 °C | 2.36 mm | 0.093 " | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Wire Wrap | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | -65 ░C | 125 °C | 2.36 mm | 0.093 " | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder Eyelet(s) | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | -65 ░C | 125 °C | 2.36 mm | 0.093 " | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | -65 ░C | 125 °C | 1.57 mm | 0.062 in | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Wire Wrap | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | -65 ░C | 125 °C | 2.36 mm | 0.093 " | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder Eyelet(s) | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | -65 ░C | 125 °C | 1.57 mm | 0.062 in | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Wire Wrap | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | -65 ░C | 125 °C | 2.36 mm | 0.093 " | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | -65 ░C | 125 °C | 1.57 mm | 0.062 in | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Copper Alloy | -65 ░C | 125 °C | 1.57 mm | 0.062 in | 2 | Female | Non Specified - Dual Edge | Green | Panel Mount Through Hole | Gold | Solder | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 29 | 5.08 mm | 0.2 in | 3.25 mm | 0.128 " | Card Guides | -65 ░C | 125 °C | 1.57 mm | 0.062 in | Non Specified - Dual Edge | Green | Contacts Not Included | UL94 V-0 |
