395-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 7POS 0.100
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Contact Material | Mounting Type | Contact Finish | Number of Positions | Number of Positions/Bay/Row | Color | Gender | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Contact Type | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | 2.95 mm | 0.116 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Wire Wrap | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Wire Wrap | 0.25 Ám | 10 Áin | 2.95 mm | 0.116 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | 3.25 mm | 0.128 " | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.1 " | 2.54 mm | Copper Alloy | Right Angle Through Hole | Gold | 7 | 7 | Black | Female | Solder | 0.25 Ám | 10 Áin | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Non Specified - Single Edge | Cantilever | 4-40 Threaded Insert Top Mount Opening | Card Guides |
