2842280 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

42P,2MM,SHRD HDR,DRVT,SMD,0.76AU

Part	Insulation Color	Termination	Contact Finish - Post	Number of Positions	Current Rating (Amps)	Number of Rows	Operating Temperature [Max]	Operating Temperature [Min]	Shrouding	Connector Type	Contact Material	Voltage Rating	Contact Finish - Mating	Row Spacing - Mating	Row Spacing - Mating	Pitch - Mating [x]	Pitch - Mating [x]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Type	Number of Positions Loaded	Contact Shape	Mounting Type	Contact Length - Mating	Contact Length - Mating	Fastening Type	Style	Insulation Material	Insulation Height [z]	Insulation Height [z]	Features	Material Flammability Rating	Contact Finish Thickness - Post	Contact Finish Thickness - Post
TE Connectivity Raychem Cable Protection 4-2842280-2	Black	Solder	Tin	42	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 3-2842280-2	Black	Solder	Tin		2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 2-2842280-2	Black	Solder	Tin	22 positions	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 5-2842280-0	Black	Solder	Tin	50	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 3-2842280-4	Black	Solder	Tin	34	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 1-2842280-0	Black	Solder	Tin	10	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 4-2842280-6	Black	Solder	Tin	46	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 1-2842280-2	Black	Solder	Tin	12	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 3-2842280-0	Black	Solder	Tin	30	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
TE Connectivity Raychem Cable Protection 4-2842280-4	Black	Solder	Tin	44	2 A	2	125 °C	-40 °C	Shrouded - 2 Wall	Header	Copper Alloy	125 VAC	Gold	0.079 in	2 mm	0.079 in	2 mm	30 Áin	0.76 Ám	Male Pin	All	Square	Surface Mount	3.7 mm	0.146 in	Detent Lock	Board to Board Cable	Thermoplastic	6.4 mm	0.252 in	Pick and Place	UL94 V-0	2 çm	78.7 çin
