0436-0 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN PIN RCPT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Contact Material	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Min]	Tail Type	Flange Diameter [diameter]	Flange Diameter [diameter]	Contact Finish Thickness	Contact Finish Thickness	Termination	Socket Depth	Socket Depth	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Length - Overall	Length - Overall
Mill-Max Manufacturing Corp. 0436-0-15-80-03-80-10-0	-55 C	125 °C	Tin	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	200 Áin	5.08 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-01-03-01-10-0	-55 C	125 °C	Tin-Lead	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	200 Áin	5.08 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-01-03-14-10-0	-55 C	125 °C	Gold	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	10 Áin	0.25 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-15-03-14-10-0	-55 C	125 °C	Gold	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	10 Áin	0.25 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-80-03-14-10-0	-55 C	125 °C	Gold	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	10 Áin	0.25 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-01-03-27-10-0	-55 C	125 °C	Gold	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	30 Áin	0.76 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
Mill-Max Manufacturing Corp. 0436-0-15-15-03-27-10-0	-55 C	125 °C	Gold	0.102 in	2.59 mm	Beryllium Copper	0.06 in	1.52 mm	0.04 in	1.02 mm	No Tail	3 mm	0.118 in	30 Áin	0.76 Ám	Solder	0.255 in	6.48 mm	1.98 mm	0.078 in	0.29 in	7.37 mm
