M18-4V Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
M18-4 SERIES: STAINLESS: DIFFUSE REFLECTIVE
| Part | Ingress Protection | Light Source | Sensing Method | Adjustment Type | Connection Method | Sensing Distance | Sensing Distance | Voltage - Supply [Min] | Voltage - Supply [Max] | Response Time | Output Configuration | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC 60529 IP67 IP68 IP69K | Red LED | Diffuse | 250° Turn Potentiometer Adjustable | Connector M12 | 30 cm | 11.811 " | 10 VDC | 30 VDC | 1.5 ms | NPN | 70 °C | -40 C |
 BANNER ENGINEERING | IEC 60529 IP67 IP68 IP69K | Red LED | 250° Turn Potentiometer Adjustable | Connector M12 | 5 cm | 1.969 in | 10 VDC | 30 VDC | 1.5 ms | PNP | 70 °C | -40 C | |
BANNER ENGINEERING | IEC 60529 IP67 IP68 IP69K | Red LED | 250° Turn Potentiometer Adjustable | Connector M12 | 15 cm | 5.906 " | 10 VDC | 30 VDC | 1.5 ms | PNP | 70 °C | -40 C |
