C44ASG Series

Manufacturer: KEMET

Catalog

CAP FILM 4UF 5% 1.5KVDC RADIAL

Part	Tolerance	Termination	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	ESR (Equivalent Series Resistance)	Capacitance	Applications	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Lead Spacing	Lead Spacing	Dielectric Material	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage Rating - AC	Voltage Rating - DC	Voltage Rating - DC	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
KEMET C44ASGP4400ZA0J	5 %	Threaded Male	Chassis Stud Mount	103 mm	4.055 in	2 mOhms	4 µF	General Purpose	Can Radial	85 °C	-40 C	22.3 mm	0.878 in	Polypropylene (PP) Metallized	2.362 in	60 mm	630 V	1.5 kV	1.5 kV
KEMET C44ASGP4500ZB0J	5 %	Threaded Male	Chassis Stud Mount	103 mm	4.055 in	2 mOhms	5 µF	General Purpose	Can Radial	85 °C	-40 C	22.3 mm	0.878 in	Polypropylene (PP) Metallized	2.559 in	65 mm	630 V	1.5 kV	1.5 kV
KEMET C44ASGP5100ZA0J	5 %	Threaded Male	Chassis Mount			3 mOhm	10 µF	General Purpose	Can Radial	85 °C	-40 C	22.3 mm	0.878 in	Polypropylene (PP) Metallized	2.756 in	70 mm	630 V	1.5 kV	1.5 kV	140 mm	5.512 "
