Nch 60V 150A, HSOP8, Power MOSFET
Description
AI
RS6L120BH is a power MOSFET with low-on resistance and High power small mold package, suitable for switching, motor drives and DC/DC converter.
Beta
⌘K
Nch 60V 150A, HSOP8, Power MOSFET
Nch 60V 150A, HSOP8, Power MOSFET
| Part | Vgs (Max) | Drain to Source Voltage (Vdss) | Operating Temperature | Power Dissipation (Max) | FET Type | Mounting Type | Rds On (Max) @ Id, Vgs | Gate Charge (Qg) (Max) @ Vgs | Current - Continuous Drain (Id) @ 25°C | Technology | Supplier Device Package | Package / Case | Input Capacitance (Ciss) (Max) @ Vds [Max] | Drive Voltage (Max Rds On, Min Rds On) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 20 V | 60 V | 150 °C | 3 W 104 W | N-Channel | Surface Mount | 2.7 mOhm | 51 nC | 120 A | MOSFET (Metal Oxide) | 8-HSOP | 8-PowerTDFN | 4080 pF | 6 V 10 V |
