YB25KK Series

Catalog

SWITCH PUSHBUTTON DPDT 0.4VA 28V

Part	Electrical Life	Mechanical Life	Voltage Rating - AC	Color - Actuator/Cap	Mounting Type	Actuator Marking	Circuit	Type	Current Rating (Amps)	Panel Cutout Dimensions [diameter]	Features	Voltage Rating - DC	Operating Temperature [Max]	Operating Temperature [Min]	Termination Style	Illumination Voltage (Nominal)	Actuator Type	Illumination Type, Color	Switch Function
NKK Switches YB25KKG01-2CF02-JB	100000 Cycles	1000000 Cycles	28 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	0.4 VA	16 mm	Voltage Reduction Lighting	28 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	2 VDC	Button Square	Green/Red LED	On-Mom
NKK Switches YB25KKW03-5C05-JB	100000 Cycles	1000000 Cycles	125 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	3 A	16 mm	Voltage Reduction Lighting	30 V	50 °C	-25 °C	PC Pin	5 VDC	Button Square	LED Red	On-Mom
NKK Switches YB25KKW01-6G-JB	100000 Cycles	1000000 Cycles	125 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	3 A	16 mm	Voltage Reduction Lighting	30 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	3.6 VDC	Button Square	Blue LED	On-Mom
NKK Switches YB25KKG01-5C05-JC	100000 Cycles	1000000 Cycles	28 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	0.4 VA	16 mm	Voltage Reduction Lighting	28 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	5 VDC	Button Square	LED Red	On-Mom
NKK Switches YB25KKW01-5D-JB	100000 Cycles	1000000 Cycles	125 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	3 A	16 mm	Voltage Reduction Lighting	30 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	2 VDC	Button Square	Amber LED	On-Mom
NKK Switches YB25KKW01-5C24-JC	100000 Cycles	1000000 Cycles	125 V	Clear	Panel Mount Snap-In		DPDT	Illuminated Standard	3 A	16 mm		30 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	1.9 VDC	Button Square	LED Red	On-Mom
NKK Switches YB25KKG01-6B-JB	100000 Cycles	1000000 Cycles	28 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	0.4 VA	16 mm	Voltage Reduction Lighting	28 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	3.3 VDC	Button Square	LED White	On-Mom
NKK Switches YB25KKW01-BB	100000 Cycles	1000000 Cycles	125 V	White	Panel Mount Snap-In	No Marking	DPDT	Standard	3 A	16 mm	Voltage Reduction Lighting	30 V	70 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)		Button Square		On-Mom
NKK Switches YB25KKG01-5F05-JF	100000 Cycles	1000000 Cycles	28 V	Clear	Panel Mount Snap-In	No Marking	DPDT	Illuminated Standard	0.4 VA	16 mm	Voltage Reduction Lighting	28 V	50 °C	-25 °C	Solder Quick Connect - 0.110" (2.8mm)	5 VDC	Button Square	Green LED	On-Mom
NKK Switches YB25KKW03	100000 Cycles	1000000 Cycles	125 V		Panel Mount Snap-In	No Marking	DPDT	Standard	3 A	16 mm	Voltage Reduction Lighting	30 V	70 °C	-25 °C	PC Pin		Plunger for Cap		On-Mom
