PT78HT2 Series
Manufacturer: Texas Instruments
Beta
⌘K
MODULE DC-DC 1-OUT 5.25V 2A 3-PIN(3+2TAB) SIP MODULE
| Part | Voltage - Output 1 | Voltage - Input (Max) [Max] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Number of Outputs | Efficiency | Voltage - Input (Min) [Min] | Package / Case | Type | Mounting Type | Current - Output (Max) [Max] | Features | Applications | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 5.25 V | 28 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 1 | 85 % | 9 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole Right Angle | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
 Texas Instruments | 5.25 V | 28 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | 1 | 85 % | 9 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 3.3 V | 15 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 1 | 80 % | 9 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole Right Angle | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 3.3 V | 15 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | 1 | 80 % | 9 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
 Texas Instruments | 5 V | 28 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 1 | 85 % | 9 V | 3-SMD Module | Non-Isolated PoL Module | Surface Mount | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 6.5 V | 28 V | 22.9 mm | 23.9 mm | 8.6 mm | 0.9 " | 0.34 in | 0.94 in | 1 | 85 % | 10.5 V | 3-SMD Module | Non-Isolated PoL Module | Surface Mount | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 8 V | 28 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 1 | 90 % | 3-SIP Module | Non-Isolated PoL Module | Through Hole Right Angle | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C | |
Texas Instruments | 5 V | 28 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | 1 | 85 % | 9 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 6.5 V | 28 V | 22.9 mm | 23.9 mm | 7.9 mm | 0.9 " | 0.31 in | 0.94 in | 1 | 85 % | 10.5 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole Right Angle | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
Texas Instruments | 6.5 V | 28 V | 7.9 mm | 22.9 mm | 23.9 mm | 0.31 " | 0.94 in | 0.9 " | 1 | 85 % | 10.5 V | 3-SIP Module | Non-Isolated PoL Module | Through Hole | 2 A | OTP SCP | ITE (Commercial) | 85 °C | -40 °C |
