PQQ6W Series
Manufacturer: CUI Inc.
Beta
⌘K
DC-DC ISOLATED, 6 W, 9~36 VDC IN
| Part | Voltage - Isolation | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Output 1 | Features | Power (Watts) | Mounting Type | Package / Case | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Type | Current - Output (Max) [Max] | Approval Agency | Voltage - Input (Min) [Min] | Number of Outputs | Voltage - Input (Max) [Max] | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 5 V | Remote On/Off | 6 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 1.2 A | CE | 9 V | 1 | 36 V | |
CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 15 V | Remote On/Off | 6 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 400 mA | CE | 9 V | 1 | 36 V | 87 % |
CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 9 V | Remote On/Off | 6 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 667 mA | CE | 9 V | 1 | 36 V | 84 % |
CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 3.3 V | Remote On/Off | 4 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 1.35 A | CE | 9 V | 1 | 36 V | 78 % |
CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 24 V | Remote On/Off | 6 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 250 mA | CE | 9 V | 1 | 36 V | 85 % |
CUI Inc. | 1.6 kV | ITE (Commercial) | 105 C | -40 °C | 12 V | Remote On/Off | 6 W | Through Hole | 8-SIP Module 7 Leads | 0.47 " | 9.5 mm | 0.87 in | 12 mm | 0.37 in | 22 mm | Isolated Module | 500 mA | CE | 9 V | 1 | 36 V | 86 % |
