PCN2-S12 Series

Manufacturer: CUI Inc.

Catalog

DC DC CONVERTER 12V 2W

Part	Approval Agency	Voltage - Output 1	Package / Case	Type	Mounting Type	Number of Outputs	Power (Watts)	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Standard Number	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Applications	Current - Output (Max) [Max]	Efficiency	Features	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)
CUI Inc. PCN2-S12-S12-S	EN	12 V	6-SIP Module 4 Leads	Isolated Module	Through Hole	1	2 W	13.2 V	10.8 V	55032 Class A	-40 C	100 °C	1000 V	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	ITE (Commercial)	167 mA	83 %	SCP
CUI Inc. PCN2-S12-D12-S	EN	12 V	6-SIP Module 5 Leads	Isolated Module	Through Hole	2	2 W	13.2 V	10.8 V	55032 Class A	-40 C	100 °C	1000 V	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	ITE (Commercial)			SCP	-12 V	83 mA	83 mA
CUI Inc. PCN2-S12-S5-S	EN	5 V	6-SIP Module 4 Leads	Isolated Module	Through Hole	1	2 W	13.2 V	10.8 V	55032 Class A	-40 C	100 °C	1000 V	0.4 "	0.28 in	10.2 mm	7.2 mm	19.6 mm	0.77 in	ITE (Commercial)	400 mA		SCP
