LCM-40 Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
I/P 180~295VAC O/P 350~1050MA
| Part | Mounting Type | Current - Output (Max) [Max] | Voltage - Isolation | Topology | Features | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Efficiency | Type | Number of Outputs | Power (Watts) | Voltage - Input (Max) [Max] | Voltage - Output [Min] | Voltage - Output [Max] | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Termination Style | Voltage - Input (Min) [Min] | Dimming |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | Chassis Mount | 1.05 A | 3750 VDC | AC DC Converter | OTP OVP SCP | 3.21 " | 23 mm | 4.86 " | 81.5 mm | 123.5 mm | 0.91 " | 90 % | Constant Current | 6 | 42 W | 295 VAC | 2 V | 100 VDC | CB CCC CE EAC ENEC | -30 ░C | 90 °C | Terminal Block | 180 VAC | |
 MEAN WELL USA Inc. | Chassis Mount | 1.05 A | 3750 VDC | AC DC Converter | OTP OVP SCP | 3.21 " | 23 mm | 4.86 " | 81.5 mm | 123.5 mm | 0.91 " | 91 % | Constant Current | 1 | 42 W | 295 VAC | 2 V | 100 VDC | CB CCC CE cURus ENEC | -30 ░C | 90 °C | Terminal Block | 180 VAC | DALI |
 MEAN WELL USA Inc. | Chassis Mount | 1.05 A | 3750 VDC | AC DC Converter | OTP OVP SCP | 3.21 " | 23 mm | 4.86 " | 81.5 mm | 123.5 mm | 0.91 " | 87.5 % | Constant Current | 1 | 35 W | 132 VAC | 2 V | 100 VDC | -30 ░C | 90 °C | Terminal Block | 90 VAC | Analog PWM |
