SI86SS41 Series

Catalog

6.0 KVRMS SPI COMPATIBLE ISOLATO

Part	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Mounting Type	Number of Channels [custom]	Technology	Supplier Device Package	Common Mode Transient Immunity (Min) [Min]	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Data Rate	Voltage - Isolation	Pulse Width Distortion (Max) [Max]	Package / Case	Package / Case	Package / Case	Type	Channel Type	Propagation Delay tpLH / tpHL (Max) [Max] [x]	Propagation Delay tpLH / tpHL (Max) [Max] [y]	Grade	Qualification	Propagation Delay tpLH / tpHL (Max) [custom]	Propagation Delay tpLH / tpHL (Max) [custom]	Package / Case
Skyworks Solutions Inc. SI86SS41EE-IS2R	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	100 V/ns	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	6000 Vrms	2 ns	16-SOIC	7.5 mm	0.295 "	SPI	Unidirectional	14 ns	14 ns
Skyworks Solutions Inc. SI86SS41BC-AS1	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	3750 Vrms	2 ns	16-SOIC			SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns	0.154 in 3.9 mm
Skyworks Solutions Inc. SI86SS41EC-AS1R	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	3750 Vrms	2 ns	16-SOIC			SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns	0.154 in 3.9 mm
Skyworks Solutions Inc. SI86SS41BE-AS2	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	6000 Vrms	2 ns	16-SOIC	7.5 mm	0.295 "	SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns
Skyworks Solutions Inc. SI86SS41EE-AS2R	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	6000 Vrms	2 ns	16-SOIC	7.5 mm	0.295 "	SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns
Skyworks Solutions Inc. SI86SS41BC-AS1R	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	3750 Vrms	2 ns	16-SOIC			SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns	0.154 in 3.9 mm
Skyworks Solutions Inc. SI86SS41BE-IS2	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	100 V/ns	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	6000 Vrms	2 ns	16-SOIC	7.5 mm	0.295 "	SPI	Unidirectional	14 ns	14 ns
Skyworks Solutions Inc. SI86SS41EC-IS1	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	100 V/ns	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	3750 Vrms	2 ns	16-SOIC			SPI	Unidirectional	14 ns	14 ns					0.154 in 3.9 mm
Skyworks Solutions Inc. SI86SS41EC-AS1	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	3750 Vrms	2 ns	16-SOIC			SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns	0.154 in 3.9 mm
Skyworks Solutions Inc. SI86SS41EE-AS2	2.5 ns	2.5 ns	Surface Mount	4	Capacitive Coupling	16-SOIC	150 kV/µs	3	1	2.25 V	5.5 V	125 °C	-40 C	150 Mbps	6000 Vrms	2 ns	16-SOIC	7.5 mm	0.295 "	SPI	Unidirectional			Automotive	AEC-Q100	42 ns	42 ns
