846-070 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Positions/Bay/Row | Number of Rows [custom] | Mounting Type | Color | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Pitch | Pitch | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Wire Wrap | 125 °C | -40 C | Copper Alloy | Cantilever | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Board Edge Straddle Mount | Green | Female | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder | 125 °C | -40 C | Copper Alloy | Cantilever | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder | 125 °C | -40 C | Copper Alloy | Cantilever | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder | 125 °C | -40 C | Copper Alloy | Cantilever | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Wire Wrap | 125 °C | -40 C | Copper Alloy | Cantilever | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Wire Wrap | 125 °C | -40 C | Copper Alloy | Cantilever | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder | 125 °C | -40 C | Copper Alloy | Cantilever | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | Flush Mount M3 Threaded Insert Top Opening | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Wire Wrap | 125 °C | -40 C | Copper Alloy | Cantilever | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Through Hole | Green | Female | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder | 125 °C | -40 C | Copper Alloy | Cantilever | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 70 | 0.25 Ám | 10 Áin | Gold | 35 | 2 | Board Edge Straddle Mount | Green | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Non Specified - Dual Edge | 3.18 mm | 0.125 in | Solder Eyelet(s) | 125 °C | -40 C | Copper Alloy | Cantilever | Card Extender |
