807-084 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 84POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Termination | Mounting Type | Read Out | Number of Positions/Bay/Row | Number of Positions [custom] | Pitch | Pitch | Contact Type | Contact Material | Contact Finish | Gender | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Single | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | Green | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Board Edge Straddle Mount | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 2 | Green | Card Extender |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Through Hole | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Through Hole | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 2 | Green | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Single | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Tin | Female | Non Specified - Dual Edge | 2 | Green | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Single | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | 2 | Green | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Board Edge Straddle Mount | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Tin | Female | Non Specified - Dual Edge | 2 | Green | Card Extender | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Board Edge Straddle Mount | Dual | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Gold | Female | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 2 | Green | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Right Angle Through Hole | Single | 42 | 84 | 3.96 mm | 0.156 in | Semi Bellows | Copper Alloy | Tin | Female | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 2 | Green |
