19S601 Series
Manufacturer: Rosenberger
Beta
⌘K
CONN SMP PLUG STR 50OHM SOLDER
| Part | Center Contact Plating | Operating Temperature [Max] | Operating Temperature [Min] | Body Finish | Includes | Mating Cycles | Dielectric Material | Body Material | Voltage Rating | Fastening Type | Center Contact Material | Shield Termination | Housing Color | Number of Ports | Connector Type | Impedance | Contact Termination | Mounting Feature | Frequency - Max [Max] | Cable Group | Features | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rosenberger | Gold | 155 C | -65 ░C | Gold | 1 Connector 1 Contact 1 Lockwasher 1 Nut | 500 | Polytetrafluoroethylene (PTFE) | Brass | 335 V | Snap-On | Brass | Solder | Gold | 1 | Plug Male Pin | 50 Ohms | Solder | Bulkhead - Front Side Nut | 26.5 GHz | RG-405 (.085" Semi Rigid) | Limited Detent | Panel Mount |
