1044AS Series
Manufacturer: Ohmite
Beta
⌘K
RES CHAS MNT 150 OHM 10% 300W
| Part | Resistance | Mounting Feature | Operating Temperature [Min] | Operating Temperature [Max] | Lead Style | Power (Watts) | Package / Case | Temperature Coefficient [Max] | Temperature Coefficient [Min] | Features | Coating, Housing Type | Size / Dimension [x] | Size / Dimension [diameter] | Size / Dimension [diameter] | Size / Dimension [x] | Composition | Tolerance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Ohmite | 150 Ohms | Brackets (not included) | -55 C | 230 °C | Ferrule Ends | 300 W | Axial Tubular | 0 ppm/°C | -800 ppm/°C | High Voltage Non-Inductive Pulse Withstanding | Ceramic | 609.6 mm | 1.5 " | 38.1 mm | 24 in | Ceramic | 10 % |
Ohmite | 100 kOhms | Brackets (not included) | -55 C | 230 °C | Ferrule Ends | 300 W | Axial Tubular | 0 ppm/°C | -800 ppm/°C | High Voltage Non-Inductive Pulse Withstanding | Ceramic | 609.6 mm | 1.5 " | 38.1 mm | 24 in | Ceramic | |
Ohmite | 60 Ohms | Brackets (not included) | -55 C | 230 °C | Ferrule Ends | 300 W | Axial Tubular | 0 ppm/°C | -800 ppm/°C | High Voltage Non-Inductive Pulse Withstanding | Ceramic | 609.6 mm | 1.5 " | 38.1 mm | 24 in | Ceramic | 10 % |
