4612X Series
Manufacturer: Bourns Inc.
Beta
⌘K
RES ARRAY 6 RES 5.6K OHM 12SIP
| Part | Resistance (Ohms) | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Tolerance | Circuit Type | Temperature Coefficient | Number of Resistors | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Power Per Element | Supplier Device Package | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Package / Case | Number of Pins | Resistance (Ohms) | Resistance (Ohms) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 5.6 kOhms | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Isolated | 100 ppm/°C | 6 | 5.08 mm | 0.2 in | 300 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Bussed | 100 ppm/°C | 11 | 5.08 mm | 0.2 in | 200 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 1k | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Bussed | 100 ppm/°C | 11 | 5.08 mm | 0.2 in | 200 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 1.5 k | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Isolated | 100 ppm/°C | 6 | 5.08 mm | 0.2 in | 300 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 4.7 kOhms | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Isolated | 100 ppm/°C | 6 | 5.08 mm | 0.2 in | 300 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 560 Ohms | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Bussed | 100 ppm/°C | 11 | 5.08 mm | 0.2 in | 200 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 10k | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Bussed | 100 ppm/°C | 11 | 5.08 mm | 0.2 in | 200 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 100k | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Isolated | 100 ppm/°C | 6 | 5.08 mm | 0.2 in | 300 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 1.8k | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Isolated | 100 ppm/°C | 6 | 5.08 mm | 0.2 in | 300 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 | 330 Ohms | ||
Bourns Inc. | 2.49 mm | 0.098 in | 1.198 " | 30.43 mm | 2 % | Dual Terminator | 100 ppm/°C | 20 | 5.08 mm | 0.2 in | 200 mW | 12-SIP | -55 C | 125 °C | Through Hole | 12-SIP | 12 |
