837-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 11POS 0.156
| Part | Termination Rows | Material - Insulation | Flange Feature | Gender | Pitch | Pitch | Card Type | Color | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Read Out | Termination | Contact Type | Number of Positions | Number of Rows | Mounting Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder | Cantilever | 11 | 1 | Right Angle Through Hole | 11 | 125 °C | -40 C | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 4-40 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Wire Wrap | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder Eyelet(s) | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Flush Mount Top Opening Unthreaded | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder Eyelet(s) | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Side Mount Opening Unthreaded | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Floating Bobbin Flush Mount | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Wire Wrap | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | M3 Threaded Insert Top Mount Opening | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Solder Eyelet(s) | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 3.96 mm | 0.156 in | Non Specified - Single Edge | Green | Gold | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Wire Wrap | Cantilever | 11 | 1 | Through Hole | 11 | 125 °C | -40 C | Copper Alloy |
