316-47 Series
Manufacturer: Mill-Max Manufacturing Corp.
Beta
⌘K
CONN SOCKET 28POS 0.1 GOLD PCB
| Part | Contact Shape | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Insulation Material | Contact Material | Insulation Color | Connector Type | Pitch - Mating | Pitch - Mating | Termination | Contact Type | Material Flammability Rating | Number of Positions | Contact Finish Thickness - Mating | Contact Finish - Post | Number of Positions Loaded | Number of Rows | Fastening Type | Contact Length - Post | Contact Length - Post | Contact Finish - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Current Rating (Amps) | Insulation Height [custom] | Insulation Height [custom] | Insulation Height | Insulation Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 28 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.236 " | 6 mm | ||
 Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 5 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.594 in | 15.09 mm | ||
Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 60 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.236 " | 6 mm | ||
 Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 15 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.315 in | 8 mm | ||
 Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 40 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.594 in | 15.09 mm | ||
 Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 2 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.236 " | 6 mm | ||
Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 62 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.594 in | 15.09 mm | ||
Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 45 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.594 in | 15.09 mm | ||
Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | 16 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.236 " | 6 mm | ||
Mill-Max Manufacturing Corp. | Circular | 200 µin | 5.08 µm | Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Black | Elevated Socket | 0.1 " | 2.54 mm | Solder | Female Socket | UL94 V-0 | Flash | Tin | All | 1 | Push-Pull | 0.118 in | 3 mm | Gold | -55 C | 125 °C | Through Hole | 3 A | 0.315 in | 8 mm |
