845-048 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 48POS 0.100
| Part | Material - Insulation | Termination Rows [custom] | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Number of Rows [custom] | Pitch | Pitch | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Color | Card Type | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Mounting Type | Termination | Read Out | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Termination Rows | Flange Feature | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 24 | 125 °C | -40 C | Female | 2 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Wire Wrap | Dual | 3.25 mm | 0.128 " | Cantilever | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 48 | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Wire Wrap | Single | Cantilever | 1 | 4-40 Threaded Insert Top Mount Opening | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 48 | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Solder | Single | Cantilever | 1 | M3 Threaded Insert Top Mount Opening | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 24 | 125 °C | -40 C | Female | 2 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Gold | 0.25 Ám | 10 Áin | 48 | Right Angle Through Hole | Solder | Dual | 2.95 mm | 0.116 " | Cantilever | Floating Bobbin Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 24 | 125 °C | -40 C | Female | 2 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Gold | 0.25 Ám | 10 Áin | 48 | Right Angle Through Hole | Solder | Dual | 3.25 mm | 0.128 " | Cantilever | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 48 | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Wire Wrap | Single | 3.25 mm | 0.128 " | Cantilever | 1 | Side Mount Opening Unthreaded | 1 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 24 | 125 °C | -40 C | Female | 2 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Solder | Dual | 3.25 mm | 0.128 " | Cantilever | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 48 | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Solder | Single | 3.96 mm | 0.156 " | Cantilever | 1 | 1 | |||
EDAC Inc. | Diallyl Phthalate (DAP) | 48 | 125 °C | -40 C | Female | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Solder Eyelet(s) | Single | 3.25 mm | 0.128 " | Cantilever | 1 | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 24 | 125 °C | -40 C | Female | 2 | 0.1 " | 2.54 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | Gold | 0.25 Ám | 10 Áin | 48 | Through Hole | Solder | Dual | Cantilever | 4-40 Threaded Insert Top Mount Opening |
