29879 Series
Manufacturer: Phoenix Contact
Beta
⌘K
POWER RELAY 120VAC 8A DPDT(29X12.7X25)MM THT
| Part | Coil Resistance | Release Time | Relay Type | Coil Voltage | Approval Agency | Contact Rating (Current) | Termination Style | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Operate Time | Contact Material | Contact Form | Switching Voltage | Features | Coil Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 8.1 kOhms | 8 ms | General Purpose | 120 VAC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Mechanical Indicator Test Button | 7 mA |
 Phoenix Contact | 1.3 kOhms | 6 ms | General Purpose | 24 VDC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 9 ms | Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Diode Lighted Indicator Mechanical Indicator Test Button | 18 mA |
 Phoenix Contact | 65.71 kOhms | 8 ms | General Purpose | 230 VAC | cULus EAC UR | 16 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Gold (Au) Silver Nickel (AgNi) | SPDT (1 Form C) | 250 VAC 250 VDC | Diode Lighted Indicator Mechanical Indicator Test Button | 3.5 mA |
 Phoenix Contact | 750 Ohms | 8 ms | General Purpose | 24 VAC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Mechanical Indicator Test Button | 32 mA |
 Phoenix Contact | 1.33 kOhms | 6 ms | General Purpose | 24 VDC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 9 ms | Gold (Au) Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Diode Lighted Indicator Mechanical Indicator Test Button | 18 mA |
 Phoenix Contact | 1.41 kOhms | 6 ms | General Purpose | 24 VDC | cULus EAC UR | 16 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 9 ms | Gold (Au) Silver Nickel (AgNi) | SPDT (1 Form C) | 250 VAC 250 VDC | Diode Lighted Indicator Mechanical Indicator Test Button | 17 mA |
 Phoenix Contact | 65.7 kOhms | 8 ms | General Purpose | 230 VAC | cULus EAC UR | 16 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | Silver Nickel (AgNi) | SPDT (1 Form C) | 250 VAC 250 VDC | Mechanical Indicator Test Button | 3.5 mA | |
 Phoenix Contact | 65.7 kOhms | 8 ms | General Purpose | 230 VAC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Mechanical Indicator Test Button | 3.5 mA |
 Phoenix Contact | 65.71 kOhms | 8 ms | General Purpose | 230 VAC | cULus EAC UR | 8 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Gold (Au) Silver Nickel (AgNi) | DPDT (2 Form C) | 250 VAC 250 VDC | Diode Lighted Indicator Mechanical Indicator Test Button | 3.5 mA |
 Phoenix Contact | 8.1 kOhms | 8 ms | General Purpose | 120 VAC | cULus EAC UR | 16 A | PC Pin | Through Hole | 70 °C | -40 C | Non Latching | 12 ms | Silver Nickel (AgNi) | SPDT (1 Form C) | 250 VAC 250 VDC | Lighted Indicator Mechanical Indicator | 7 mA |
