835-47 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 26POS 0.1 GOLD PCB

Part	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material	Insulation Material	Insulation Height [z]	Insulation Height [z]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Termination	Contact Length - Post	Contact Length - Post	Contact Type	Number of Positions Loaded	Material Flammability Rating	Insulation Color	Operating Temperature [Min]	Operating Temperature [Max]	Pitch - Mating	Pitch - Mating	Connector Type	Contact Finish - Post	Number of Rows [custom]	Fastening Type	Mounting Type	Number of Positions	Contact Finish - Mating	Contact Finish Thickness - Mating
Mill-Max Manufacturing Corp. 835-47-026-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	26	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-038-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	38	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-024-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	24	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-050-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	50	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-030-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	30	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-056-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	56	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-070-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	70	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-052-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	52	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-006-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	6	Gold	Flash
Mill-Max Manufacturing Corp. 835-47-064-10-001000	Circular	200 µin	5.08 µm	Beryllium Copper	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	0.13 in	3.3 mm	0.1 in	2.54 mm	Solder	2.03 mm	0.08 in	Female Socket	All	UL94 V-0	Black	-55 C	125 °C	0.1 "	2.54 mm	Receptacle Pass Through	Tin	2	Push-Pull	Through Hole	64	Gold	Flash
