RISH MASTER Series

Catalog

MULTI METER TOUCHSCN LCD 60-300V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Measuring Type	Display Type	Type	Mounting Type	Ingress Protection	Voltage - Supply [Max]	Voltage - Supply [Min]	Termination Style	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Panel Cutout Dimensions	Output Type
Rishabh Instruments RISH MASTER 3480 0.2-H-2	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	300 VAC/DC	60 VAC/DC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2) Digital Serial
Rishabh Instruments RISH MASTER 3480 1.0-L-Z	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2)
Rishabh Instruments RISH MASTER 3480 0.2-L-Z	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2)
Rishabh Instruments RISH MASTER 3480 0.2-L-2	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2) Digital Serial
Rishabh Instruments RISH MASTER 3480 0.5-L-1	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Digital (2) Serial
Rishabh Instruments RISH MASTER 3480 1.0-H-3	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	300 VAC/DC	60 VAC/DC	Screw Terminal	92.8 mm	92.8 mm	Square	Serial
Rishabh Instruments RISH MASTER 3480 0.5-L-Z	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2)
Rishabh Instruments RISH MASTER 3480 0.5-H-Z	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	300 VAC/DC	60 VAC/DC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2)
Rishabh Instruments RISH MASTER 3480 0.2-L-3	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	60 VAC	12 VAC	Screw Terminal	92.8 mm	92.8 mm	Square	Serial
Rishabh Instruments RISH MASTER 3480 0.2-H-Z	55 °C	-10 °C	Current (3-Phase) Voltage Wattage	LCD	Energy Monitor	DIN Rail	IP55 - Dust Protected Water Resistant	300 VAC/DC	60 VAC/DC	Screw Terminal	92.8 mm	92.8 mm	Square	Analog (2)
