845-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 58POS 0.100
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Contact Finish | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Gender | Read Out | Card Type | Termination | Pitch | Pitch | Contact Type | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row | Mounting Type | Color | Operating Temperature [Max] | Operating Temperature [Min] | Termination Rows [custom] | Flange Feature | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | 58 | 0.156 " | 3.96 mm | Female | Single | Non Specified - Single Edge | Wire Wrap | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 58 | Through Hole | Green | 125 °C | -40 C | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | Female | Dual | Non Specified - Dual Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Through Hole | Green | 125 °C | -40 C | 2 | M3 Threaded Insert Top Mount Opening | 2 | ||||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | 58 | 0.128 " | 3.25 mm | Female | Single | Non Specified - Single Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 58 | Through Hole | Green | 125 °C | -40 C | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | 58 | 0.156 " | 3.96 mm | Female | Single | Non Specified - Single Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 58 | Through Hole | Green | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | 0.156 " | 3.96 mm | Female | Dual | Non Specified - Dual Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Through Hole | Green | 125 °C | -40 C | 2 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | Female | Dual | Non Specified - Dual Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Right Angle Through Hole | Green | 125 °C | -40 C | 2 | 4-40 Threaded Insert Top Mount Opening | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | 0.116 " | 2.95 mm | Female | Dual | Non Specified - Dual Edge | Solder Eyelet(s) | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Through Hole | Green | 125 °C | -40 C | 2 | Floating Bobbin Flush Mount | 2 | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | 0.128 " | 3.25 mm | Female | Dual | Non Specified - Dual Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Right Angle Through Hole | Green | 125 °C | -40 C | 2 | Side Mount Opening Unthreaded | 2 | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Gold | 58 | 0.128 " | 3.25 mm | Female | Single | Non Specified - Single Edge | Wire Wrap | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 58 | Through Hole | Green | 125 °C | -40 C | Flush Mount Top Opening Unthreaded | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 58 | Female | Dual | Non Specified - Dual Edge | Solder | 0.1 " | 2.54 mm | Cantilever | Copper Alloy | 0.25 Ám | 10 Áin | 29 | Through Hole | Green | 125 °C | -40 C | 2 | 4-40 Threaded Insert Top Mount Opening | 2 |
