EPS030100 Series

Manufacturer: CUI Inc.

Catalog

AC/DC WALL MOUNT ADAPTER 3V 3W

Part	Region Utilized	Input Connector	Form	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Cord Length	Cord Length	Power (Watts)	Efficiency	Applications	Approval Agency	Voltage - Input [Min]	Voltage - Input [Max]	Current - Output (Max) [Max]	Input Type	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Voltage - Output	Output Connector [z]	Output Connector [diameter]	Output Connector	No Load Power Consumption
CUI Inc. EPS030100-P6RP	North America	NEMA 1-15P	Wall Mount	Positive Center	40 °C	0 °C	1.83 m	72 in	3 W	Level IV	ITE (Commercial)	cULus	100 VAC	132 VAC	1 A	Fixed Blade	1.65 "	26.8 mm	42 mm	1.06 in	62.3 mm	2.45 in	3 V	12 mm	2.5 mm 5.5 mm	Barrel Plug R/A	500 mW
CUI Inc. EPS030100-P5RP	North America	NEMA 1-15P	Wall Mount	Positive Center	40 °C	0 °C	1.83 m	72 in	3 W	Level IV	ITE (Commercial)	cULus	100 VAC	132 VAC	1 A	Fixed Blade	1.65 "	26.8 mm	42 mm	1.06 in	62.3 mm	2.45 in	3 V	12 mm	2.1 mm 5.5 mm	Barrel Plug R/A	500 mW
