845-051 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 51POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row [custom] | Contact Material | Color | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Gender | Card Type | Mounting Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions | Number of Rows | Contact Type | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | Flush Mount Side Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Right Angle Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | Floating Bobbin Top Mount Opening |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Wire Wrap | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | 4-40 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 3.96 mm | 0.156 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Right Angle Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | Flush Mount Top Opening Unthreaded |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 125 °C | -40 C | 51 | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Female | Non Specified - Single Edge | Right Angle Through Hole | Solder | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | 51 | 1 | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening |
