80 V common-mode, Current Sense Amplifiers
Key Features
• Bandwidth: 100 kHz
• Input Offset Voltage: ±300 µV Max Over Temp
• Common−Mode Input Voltage Range: −6 V to 80 V Operating, −14 V to 85 V Survival
• Gain Error: ±0.3 % Max Over Temp
• Low−Pass Filter (1−pole or 2−pole)
• Offset Drift over Temperature: ±3 V/°C max
• Quiescent Current: 1.5 mA Typ
• Supply Voltage: 3 V to 5.5 V
• CMRR: 85 dB Min
• PSRR: 75 dB Min
Description
AI
The NCS(V)7030 and NCS(V)7031 are high voltage, current sense amplifiers. They are available with gain options of 14 V/V and 20 V/V, with a maximum ±0.3 % gain error over the entire temperature range. Each part consists of a preamplifier and buffer with access to output and input via A1 and A2 pins for an intermediate filter network or modified gain. The current sense amplifiers offer excellent input common−mode rejection from −6 V to 80 V. They can perform unidirectional current measurements across a sense resistor in a variety of applications. Automotive qualified options are available under NCV prefix. All versions are specified over the extended operating temperature range from −40°C to 150°C.Similar Products:
