637-M44 Series
Manufacturer: EDAC Inc.
Beta
⌘K
637M SERIES VERTICAL D-SUB PLUG
| Part | Contact Material | Color | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Flange Feature | Flange Feature | Connector Style | Contact Finish | Shell Size, Connector Layout | Current Rating (Amps) | Features | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Connector Type | Contact Type | Number of Positions | Shell Material, Finish | Termination | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Free Hanging (In-Line) | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | 0.38 µm | 15 µin | UL94 V-0 | Plug Male Pins | Signal | 44 | |||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Through Hole | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | 0.38 µm | 15 µin | UL94 V-0 | Plug Male Pins | Signal | 44 | Nickel Plated Steel | Solder | |
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Free Hanging (In-Line) | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Board Lock Grounding Indents Shielded | 3 | 0.38 µm | 15 µin | UL94 V-0 | Plug Male Pins | Signal | 44 | Nickel Plated Steel | ||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Free Hanging (In-Line) | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Board Lock Grounding Indents Shielded | 3 | UL94 V-0 | Plug Male Pins | Signal | 44 | Flash | ||||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Free Hanging (In-Line) | Housing/Shell (Unthreaded) | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | UL94 V-0 | Plug Male Pins | Signal | 44 | Flash | |||||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Through Hole | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | UL94 V-0 | Plug Male Pins | Signal | 44 | Solder | Flash | |||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Through Hole | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | UL94 V-0 | Plug Male Pins | Signal | 44 | Nickel Plated Steel | Solder | Flash | ||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Through Hole | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Board Lock Grounding Indents Shielded | 3 | UL94 V-0 | Plug Male Pins | Signal | 44 | Nickel Plated Steel | Solder | Flash | ||
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Through Hole | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | 0.38 µm | 15 µin | UL94 V-0 | Plug Male Pins | Signal | 44 | Nickel Plated Steel | Solder | |
 EDAC Inc. | Copper Alloy | Black | Nylon 9T Polyamide (PA9T) | -55 C | 125 °C | Free Hanging (In-Line) | Housing/Shell | 4-40 | D-Sub High Density | Gold | 3 | 5 A | Grounding Indents Shielded | 3 | 0.76 Ám | 30 Áin | UL94 V-0 | Plug Male Pins | Signal | 44 |
