320564 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
SPADE TONGUE TERMINAL 16AWG COPPER BLUE/BLUE STRIPE 32.51MM TIN LOOSE
| Part | Material - Insulation | Contact Finish | Insulation | Width - Outer Edges [custom] | Width - Outer Edges [custom] | Length - Overall [x] | Length - Overall [x] | Termination | Thickness | Thickness | Color | Features | Terminal Type | Stud/Tab Size | Insulation Diameter [Min] [diameter] | Insulation Diameter [Max] [diameter] | Insulation Diameter [Min] [diameter] | Insulation Diameter [Max] [diameter] | Contact Material | Wire Gauge | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Nylon Polyamide (PA) | Tin | Insulated | 13.49 mm | 0.531 " | 32.51 mm | 1.28 in | Crimp | 0.031 in | 0.79 mm | Blue Blue Stripe | Insulation Restriction Serrated Termination | Circular | 3/8 Stud | 0.063 " | 3.3 mm | 1.6 mm | 0.13 " | Copper | 16 AWG | Free Hanging (In-Line) |
