29673 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE DPDT 50MA 60V
| Part | Coil Resistance | Contact Rating (Current) | Operate Time | Relay Type | Release Time | Features | Contact Form | Coil Current | Termination Style | Mounting Type | Approval Agency | Coil Type | Contact Material | Coil Voltage | Switching Voltage [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Switching Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 6 kOhms | 50 mA | 8 ms | General Purpose | 10 ms | Diode Lighted Indicator | DPDT (2 Form C) | 10 mA | Screw Terminal | DIN Rail | cULus DNV EAC UL | Non Latching | Gold (Au) Silver Nickel (AgNi) | 60 VDC | 30 VAC 36 VDC | 60 °C | -40 C | |
 Phoenix Contact | 2.67 kOhms | 6 A | 5 ms | General Purpose | 8 ms | Lighted Indicator Socket Included | SPST-NO (1 Form A) | 9 mA | Spring Terminal | DIN Rail | Non Latching | Silver Tin Oxide (AgSnO) | 24 VDC | 60 °C | -40 C | 250 VAC 250 VDC | ||
 Phoenix Contact | 2.67 kOhms | 50 mA | 5 ms | General Purpose | 8 ms | Lighted Indicator Socket Included | SPST-NO (1 Form A) | 9 mA | Spring Terminal | DIN Rail | Non Latching | Gold (Au) Silver Tin Oxide (AgSnO) | 24 VDC | 30 VAC 36 VDC | 60 °C | -40 C |
