WTB9M4 Series
Manufacturer: SICK, Inc.
Beta
⌘K
SENSOR PROXIMITY 350MM PNP
| Part | Response Time | Connection Method | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Adjustment Turns | Adjustment Type | Output Configuration | Sensing Distance Minimum | Sensing Distance Maximum | Sensing Method | Ingress Protection | Operating Temperature (Max) | Operating Temperature (Min) | Light Source Wavelength (Red) | Light Source | Light Source Wavelength (Infrared) | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | 333 µs | Connector M12 | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | PNP | 0.787 " | 13.78 " | Proximity | IP66 IP67 IP69K | 60 °C | -40 °C | 650 nm | Red | ||
 SICK, Inc. | 500 µs | Connector M8 | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | PNP | 0.787 " | 19.685 " | Proximity | IP66 IP67 IP69K | 60 °C | -40 °C | Infrared | 880 nm | ||
 SICK, Inc. | 500 µs | Cable with Connector | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | PNP | 0.787 " | 19.685 " | Proximity | IP66 IP67 IP69K | 60 °C | -40 °C | Infrared | 880 nm | 4.724 in | |
SICK, Inc. | 333 µs | Connector M8 | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | PNP | 0.787 " | 13.78 " | Proximity | IP66 | 60 °C | -40 °C | 650 nm | Red | ||
SICK, Inc. | 500 µs | Connector M12 | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | PNP | 0.787 " | 19.685 " | Proximity | IP66 | 60 °C | -40 °C | Infrared | 880 nm | ||
 SICK, Inc. | 333 µs | Connector M8 | 10 VDC | 30 VDC | 5 turn | Adjustable Potentiometer | NPN | 0.787 " | 13.78 " | Proximity | IP66 | 60 °C | -40 °C | 650 nm | Red |
