RP305 Series

Catalog

COMPACT 3PH DELTA SNGL STAGE PWR

Part	Frequency - Operating [Max]	Frequency - Operating [Min]	Voltage - Rated AC (Phase to Ground/Neutral)	Applications	Filter Type	Voltage - Rated AC	Configuration	Approval Agency	Operating Temperature [Max]	Operating Temperature [Min]	Current	Termination Style	Mounting Type
Astrodyne TDI RP305-20-10-W	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	20 A	Wire Leads	Chassis Mount
Astrodyne TDI RP305-80-100-C	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	80 A	Terminal Block	Chassis Mount
Astrodyne TDI RP305-10-10-W	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	10 A	Wire Leads	Chassis Mount
Astrodyne TDI RP305-6-100-S	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	6 A	Threaded Post (M5)	Chassis Mount
Astrodyne TDI RP305-20-1000-W	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	20 A	Wire Leads	Chassis Mount
Astrodyne TDI RP305-40-0-C	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	40 A	Terminal Block	Chassis Mount
Astrodyne TDI RP305-40-100-S	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	40 A	Threaded Post (M5)	Chassis Mount
Astrodyne TDI RP305-6-1000-W	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	6 A	Wire Leads	Chassis Mount
Astrodyne TDI RP305-60-100-C	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	60 A	Terminal Block	Chassis Mount
Astrodyne TDI RP305-40-1000-S	60 Hz	50 Hz	3.5 kV	General Purpose	Three Phase (Delta)	480 V	Single Stage	CE CSA cURus SEMKO	100 °C	-25 °C	40 A	Threaded Post (M5)	Chassis Mount
