XR77103 Series

Catalog

KIT EVAL BOARD DEMO XR77103

Part	Board Type	Supplied Contents	Outputs and Type	Outputs and Type	Contents	Voltage - Output [Min]	Voltage - Output [Max]	Outputs and Type [custom]	Regulator Topology	Utilized IC / Part	Main Purpose	Function	Voltage - Output (Max) [Max]	Voltage - Input (Min) [Min]	Topology	Package / Case	Frequency - Switching	Number of Outputs	Operating Temperature [Min]	Operating Temperature [Max]	Output Configuration	Mounting Type	Current - Output	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Voltage - Output (Min/Fixed)	Supplier Device Package	Voltage - Input (Max) [Max]	Output Type	Frequency - Switching [Max]	Frequency - Switching [Min]
MaxLinear, Inc. XR77103EVB-DEMO-1	Fully Populated	Board(s)	Non-Isolated Non-Isolated Outputs	3	Board(s)	0.8 V	6 VDC	3	Buck	XR77103	DC/DC Step Down
MaxLinear, Inc. XR77103ELB-A0R5												Step-Down	13.3 V	4.5 V	Buck	32-VFQFN Exposed Pad	500 kHz	3	-40 C	125 °C	Positive	Surface Mount	2 A	12 V	5 V	9 V	0.8 V	32-TQFN (4x4)	14 V	Adjustable (Fixed)
MaxLinear, Inc. XR77103ELB-A1R0												Step-Down	13.3 V	4.5 V	Buck	32-VFQFN Exposed Pad	1 MHz	3	-40 C	125 °C	Positive	Surface Mount	2 A	12 V	5 V	9 V	0.8 V	32-TQFN (4x4)	14 V	Adjustable (Fixed)
MaxLinear, Inc. XR77103ELBTR												Step-Down		4.5 V	Buck	32-VFQFN Exposed Pad		3	-40 C	125 °C	Positive	Surface Mount	2 A				0.8 V	32-TQFN (4x4)	14 V	Adjustable	2.2 MHz	300 kHz
MaxLinear, Inc. XR77103ELBTR-A1R0												Step-Down	13.3 V	4.5 V	Buck	32-VFQFN Exposed Pad	1 MHz	3	-40 C	125 °C	Positive	Surface Mount	2 A	12 V	5 V	9 V	0.8 V	32-TQFN (4x4)	14 V	Adjustable (Fixed)
MaxLinear, Inc. XR77103ELBTR-A0R5												Step-Down	13.3 V	4.5 V	Buck	32-VFQFN Exposed Pad	500 kHz	3	-40 C	125 °C	Positive	Surface Mount	2 A	12 V	5 V	9 V	0.8 V	32-TQFN (4x4)	14 V	Adjustable (Fixed)
MaxLinear, Inc. XR77103EVB-A1R0	Fully Populated	Board(s)	Non-Isolated Non-Isolated Outputs	3	Board(s)	0.8 V	6 VDC	3	Buck	XR77103-A1R0	DC/DC Step Down						1 MHz						2 A
