395-018 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Read Out | Color | Termination | Gender | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows [custom] | Contact Material | Card Type | Contact Finish | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Wire Wrap | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Solder | Female | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | |||||||
 EDAC Inc. | Polyester Thermoplastic | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Single | Black | Wire Wrap | Female | M3 Threaded Insert Top Mount Opening | Copper Alloy | Non Specified - Single Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | 1 | 1 | 18 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Solder | Female | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Solder | Female | 0.128 " | 3.25 mm | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Right Angle Through Hole | -40 C | 105 ░C | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Wire Wrap | Female | 4-40 Threaded Insert Top Mount Opening | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 0.1 " | 2.54 mm | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Dual | Black | Wire Wrap | Female | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 2 | Copper Alloy | Non Specified - Dual Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Single | Black | Wire Wrap | Female | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Non Specified - Single Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | 1 | 1 | 18 | Card Guides | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Single | Black | Solder | Female | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | Non Specified - Single Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | 1 | 1 | 18 | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.1 " | 2.54 mm | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 18 | Single | Black | Wire Wrap | Female | M3 Threaded Insert Top Mount Opening | Copper Alloy | Non Specified - Single Edge | Gold | Cantilever | 0.25 Ám | 10 Áin | Through Hole | -40 C | 105 ░C | 1 | 1 | 18 |
