395-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Features | Contact Type | Color | Gender | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Material | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Read Out | Number of Positions | Termination | Number of Rows [custom] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions/Bay/Row [custom] | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Termination Rows | Number of Rows | Number of Positions/Bay/Row |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Card Extender | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Dual | 36 | Solder | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Board Edge Straddle Mount | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 0.128 " | 3.25 mm | Dual | 36 | Solder | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 0.156 " | 3.96 mm | Dual | 36 | Wire Wrap | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Card Guides | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Dual | 36 | Wire Wrap | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Card Guides | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Dual | 36 | Wire Wrap | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | M3 Threaded Insert Top Mount Opening | Single | 36 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | -40 C | 105 ░C | Right Angle Through Hole | 1 | 1 | 36 | ||||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Card Guides | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Dual | 36 | Solder | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Card Guides | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Single | 36 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | -40 C | 105 ░C | Through Hole | 1 | 1 | 36 | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Card Guides | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Dual | 36 | Solder | 2 | 0.25 Ám | 10 Áin | 18 | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | Polyester Thermoplastic | Cantilever | Black | Female | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Copper Alloy | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Single | 36 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | -40 C | 105 ░C | Right Angle Through Hole | 1 | 1 | 36 |
