HCPL-6651 Series
Manufacturer: Broadcom Limited
Beta
⌘K
OPTOISO 1.5KV OPEN COLL 16FLATPK
| Part | Current - DC Forward (If) (Max) [Max] | Propagation Delay tpLH / tpHL (Max) [custom] | Propagation Delay tpLH / tpHL (Max) [custom] | Input Type | Data Rate | Supplier Device Package | Voltage - Supply [Min] | Voltage - Supply [Max] | Current - Output / Channel | Voltage - Forward (Vf) (Typ) | Common Mode Transient Immunity (Min) [Min] | Rise / Fall Time (Typ) [custom] | Rise / Fall Time (Typ) [custom] | Package / Case | Output Type | Inputs - Side 1/Side 2 | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Isolation | Number of Channels | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Broadcom Limited | 20 mA | 100 ns | 100 ns | DC | 10 Mbps | 16-Flatpack | 4.5 V | 5.5 V | 25 mA | 1.5 V | 1 kV/µs | 35 ns | 35 ns | 16-FlatPack | Open Collector Schottky Clamped | 4/0 | -55 °C | 125 °C | 1.5 kV | 4 | Surface Mount |
