M55-610 Series

Catalog

PCB RECEPTACLE, BOARD-TO-BOARD, 1.27 MM, 2 ROWS, 12 CONTACTS, SURFACE MOUNT RIGHT ANGLE

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Material	Insulation Material	Contact Shape	Applications	Row Spacing - Mating	Row Spacing - Mating	Contact Finish - Post	Number of Positions	Fastening Type	Insulation Color	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height	Insulation Height	Features	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Voltage Rating	Termination	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Number of Rows [custom]	Current Rating (Amps)	Mounting Type	Number of Positions Loaded	Material Flammability Rating	Contact Type
Harwin Inc. M55-6101242R	2.54 µm	100 µin	Phosphor Bronze	Liquid Crystal Polymer (LCP)	Rectangular	Automotive General Purpose Industrial	0.05 in	1.27 mm	Tin	12	Latch Holder	Black	Receptacle	-55 C	125 °C	3.7 mm	0.146 in	Board Guide Solder Retention	0.025 µm	1 µin	100 VAC	Solder	Gold	1.27 mm	0.05 in	2	1.2 A	Right Angle Surface Mount	All	UL94 V-0	Female Socket
Harwin Inc. M55-6101642R	2.54 µm	100 µin	Phosphor Bronze	Liquid Crystal Polymer (LCP)	Rectangular	Automotive General Purpose Industrial	0.05 in	1.27 mm	Tin	16	Latch Holder	Black	Receptacle	-55 C	125 °C	3.7 mm	0.146 in	Board Guide Solder Retention	0.025 µm	1 µin	100 VAC	Solder	Gold	1.27 mm	0.05 in	2	1.2 A	Right Angle Surface Mount	All	UL94 V-0	Female Socket
