1213 Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE CAT5E 8CON 24AWG GRY
| Part | Voltage | Conductor Strand | Conductor Insulation | Cable Type | Jacket Color | Wire Gauge | Ratings | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Material | Features | Number of Conductors | Conductor Material | Length | Length | Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 300 VDC | Solid | Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO) | Multi-Pair Cat5e | Gray | 24 AWG | UL Style CMP | 5.26 mm | 0.207 in | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Flame Retardant Rip Cord | 8 | Copper Bare | 304.8 m | 1000 ft | Ethernet LAN Video |
 Belden Inc. | 300 VDC | Solid | Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO) | Multi-Pair Cat5e | Pink | 24 AWG | UL Style CMP | 5.26 mm | 0.207 in | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Flame Retardant Rip Cord | 8 | Copper Bare | 304.8 m | 1000 ft | Ethernet LAN Video |
 Belden Inc. | 300 VDC | Solid | Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO) | Multi-Pair Cat5e | White | 24 AWG | UL Style CMP | 5.26 mm | 0.207 in | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Flame Retardant Rip Cord | 8 | Copper Bare | 304.8 m | 1000 ft | Ethernet LAN Video |
Belden Inc. | 300 VDC | Solid | Fluorinated Ethylene-Propylene (FEP) Polyolefin (PO) | Multi-Pair Cat5e | Orange | 24 AWG | UL Style CMP | 5.26 mm | 0.207 in | Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum | Flame Retardant Rip Cord | 8 | Copper Bare | 304.8 m | 1000 ft | Ethernet LAN Video |
