9CRL0812 Series
Manufacturer: Sanyo Denki America Inc.
Beta
⌘K
FAN AXIAL DUAL 80X80MM 12VDC
| Part | Material - Blade | Current Rating (Amps) | Air Flow | Air Flow | Voltage Range [Min] | Voltage Range [Max] | Lifetime @ Temp. | Material - Frame | Bearing Type | Weight | Weight | RPM [custom] | RPM [custom] | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Static Pressure | Static Pressure | Fan Type | Noise | Power (Watts) | Size / Dimension [z] | Size / Dimension [x] | Voltage - Rated | Width [y] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | Plastic | 5.3 A | 158.9 CFM | 4.45 m³/min | 10.8 VDC | 13.2 VDC | 130000 Hrs | Aluminum | Ball | 499 g | 1.1 lbs | 11300 RPM | 12000 RPM | 4 | -20 ░C | 70 °C | cURus TUV | 1150.8 Pa | 4.62 in H2O | Tubeaxial (Dual) | 76 dB(A) | 63.6 W | 80 mm | 80 mm | 12 VDC | 80 mm | Counter-Rotating Locked Rotor Protection PWM Control Speed Sensor (Tach) |
