47 Series

Catalog

FIXED IND 2.2UH 7A 8.5 MOHM SMD

Part	Mounting Type	Type	Frequency - Self Resonant	Q @ Freq	DC Resistance (DCR) [Max]	Inductance	Tolerance	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Inductance Frequency - Test	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Shielding	Package / Case	Q @ Freq [custom]	Q @ Freq [custom]	DC Resistance (DCR)
Murata Electronics 472R2SC	Surface Mount	Wirewound	44 MHz	1 MHz 24	8.5 mOhm	2.2 µH	30 %	7 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 47221SC	Surface Mount	Wirewound	6 MHz		629 mOhm	220 µH	20 %	800 mA	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead	800 kHz	20
Murata Electronics 47100C	Surface Mount	Wirewound				10 µH		3.2 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead			70.2 mOhm
Murata Electronics 47220C	Surface Mount	Wirewound			165 mOhm	22 µH		2.1 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 47331SC	Surface Mount	Wirewound	5 MHz	21 800 kHz	940 mOhm	330 µH	20 %	700 mA	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 47680SC	Surface Mount	Wirewound	9 MHz	1 MHz 23	210 mOhm	68 µH	20 %	1.6 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 472R2C	Surface Mount	Wirewound				2.2 µH		6.8 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead			13.7 mOhm
Murata Electronics 47330C	Surface Mount	Wirewound			207 mOhm	33 µH		1.8 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 474R7SC	Surface Mount	Wirewound	34 MHz	1 MHz 25	16.4 mOhm	4.7 ÁH	30 %	5.8 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead
Murata Electronics 47150C	Surface Mount	Wirewound				15 µH		2.6 A	85 °C	-40 C	0.197 in	5 mm	10 kHz	12.2 mm	0.48 in	12.2 mm	0.48 in	Shielded	Nonstandard 4 Lead			106 mOhm
