1542004 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

25MM HS ASSY ULTEM CL

Part	Thermal Resistance @ Forced Air Flow	Material	Attachment Method	Package Cooled	Shape	Material Finish	Type	Fin Height	Fin Height	Diameter	Diameter	Diameter [diameter]	Diameter [diameter]	Thermal Resistance @ Natural	Fin Height [custom]	Fin Height [custom]	Fin Height [z]	Fin Height [z]
TE Connectivity Raychem Cable Protection 6-1542004-6	6.71 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount	11.23 mm	0.442 in	25.4 mm	1 in
TE Connectivity Raychem Cable Protection 5-1542004-7	5.99 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount	11.86 mm	0.467 in			1.375 in	34.92 mm	13.2 °C/W
TE Connectivity Raychem Cable Protection 7-1542004-1		Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount			63.25 mm	2.49 "				0.433 "	11 mm
TE Connectivity Raychem Cable Protection 6-1542004-0		Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount					1.2 in	30.48 mm		0.34 in	8.64 mm
TE Connectivity Raychem Cable Protection 6-1542004-9	3.11 °C/W 250 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount	17.22 mm	0.678 "
TE Connectivity Raychem Cable Protection 6-1542004-2	3.08 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount	10.92 mm	0.43 "			3 "	76.2 mm	5.69 °C/W
TE Connectivity Raychem Cable Protection 5-1542004-4	6 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized		11.86 mm	0.467 in			1.375 in	34.92 mm	13.2 °C/W
TE Connectivity Raychem Cable Protection 1542004-3	8.58 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount	11.23 mm	0.442 in	25.4 mm	1 in			14.51 °C/W
TE Connectivity Raychem Cable Protection 5-1542004-0	6.14 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical Pin Fins	Black Anodized	Top Mount			50.8 mm	2 "			10.1 °C/W			12.7 mm	0.5 in
TE Connectivity Raychem Cable Protection 1542004-5	5.99 °C/W 200 LFM	Aluminum	Clip	BGA	Cylindrical	Black Anodized	Top Mount			25.4 mm	1 in			14 °C/W			14.5 mm	0.571 in
