LCD6 Series

Catalog

CONN TERM RECT TONG 6 AWG #3/8

Part	Contact Material	Diameter - Ring ID [diameter]	Diameter - Ring ID [diameter]	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Contact Finish	Terminal Type	Wire Gauge	Tab Thickness [custom]	Tab Thickness [custom]	Terminal Style	Color	Termination	Stud/Tab Size	Width - Outer Edges	Width - Outer Edges	Mounting Type	Insulation	Diameter - Ring ID	Diameter - Ring ID	Tab Thickness	Tab Thickness	Length - Overall	Length - Overall	Diameter - Ring ID	Width - Outer Edges [x]	Width - Outer Edges [x]	Length - Overall [x]	Length - Overall [x]
Panduit Corp LCD6-38DH-L	Copper	10.41 mm	0.41 "	0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG	0.06 in	1.52 mm	Two Stud Holes	Blue	Barrel Crimp	0.375 Stud	0.62 in	15.75 mm	Free Hanging (In-Line)	Non-Insulated
Panduit Corp LCD6-56D-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.3125 Stud	0.56 in	14.22 mm	Free Hanging (In-Line)	Non-Insulated	8.64 mm	0.34 in	1.78 mm	0.07 in	69.34 mm	2.73 in
Panduit Corp LCD6-14AH-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.25 Stud			Free Hanging (In-Line)	Non-Insulated		6.86 mm	2.03 mm	0.08 "			0.27 in	12.19 mm	0.48 "
Panduit Corp LCD6-14B-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.25 Stud			Free Hanging (In-Line)	Non-Insulated		6.86 mm	2.03 mm	0.08 "	59.94 mm	2.36 in	0.27 in	12.19 mm	0.48 "
Panduit Corp LCD6-14A-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Lug Grounding	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.25 Stud			Free Hanging (In-Line)	Non-Insulated		6.86 mm	2.03 mm	0.08 "			0.27 in	12.19 mm	0.48 "	56.9 mm	2.24 in
Panduit Corp LCD6-10BH-L	Copper	5.08 mm	0.2 in	0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	10 Stud			Free Hanging (In-Line)	Non-Insulated			2.03 mm	0.08 "				11.68 mm	0.46 in
Panduit Corp LCD6-12F-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.5 Stud			Free Hanging (In-Line) Right Angle	Non-Insulated	13.46 mm	0.53 in	3.05 mm	0.12 in				19.05 mm	0.75 in
Panduit Corp LCD6-10DH-L	Copper	5.08 mm	0.2 in	0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	10 Stud			Free Hanging (In-Line)	Non-Insulated			2.03 mm	0.08 "				11.68 mm	0.46 in
Panduit Corp LCD6-12-L	Copper			0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	0.5 Stud			Free Hanging (In-Line)	Non-Insulated	13.46 mm	0.53 in	3.05 mm	0.12 in	101.35 mm	3.99 in		19.05 mm	0.75 in
Panduit Corp LCD6-10AF-L	Copper	5.08 mm	0.2 in	0.31 in	7.87 mm	0.22 in	5.59 mm	Electro-Tin	Rectangular Tongue	6 AWG			Two Stud Holes	Blue	Barrel Crimp	10 Stud			Free Hanging (In-Line) Right Angle	Non-Insulated			2.03 mm	0.08 "				11.68 mm	0.46 in
