NID65 Series
Manufacturer: MEAN WELL USA Inc.
Beta
⌘K
DC DC CONVERTER 5V 33W
| Part | Power (Watts) | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Current - Output (Max) [Max] | Applications | Voltage - Output 1 | Number of Outputs | Features | Voltage - Input (Min) [Min] | Package / Case | Efficiency | Voltage - Input (Max) [Max] | Mounting Type | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 MEAN WELL USA Inc. | 33 W | 50.8 mm | 0.43 in | 1.02 in | 11 mm | 26 mm | 50.8 mm | 6.5 A | ITE (Commercial) | 5 V | 1 | OCP OVP Remote On/Off SCP | 10.5 V | 11-SIP Module | 93 % | 53 V | Through Hole | CE EAC | 85 °C | -30 °C | Non-Isolated PoL Module |
