612N Series

Catalog

FAN AXIAL 60X25.4MM 12VDC WIRE

Part	Material - Blade	Lifetime @ Temp.	Current Rating (Amps)	Material - Frame	Voltage Range [Min]	Voltage Range [Max]	Fan Type	Weight	Weight	RPM	Air Flow	Air Flow	Approval Agency	Bearing Type	Noise	Width [y]	Power (Watts)	Voltage - Rated	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Size / Dimension [z]	Size / Dimension [x]	Operating Temperature	Operating Temperature [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature	Operating Temperature	Features	Static Pressure	Static Pressure
ebm-papst Inc. 612NGHH	Polyamide (PA) Nylon Fiberglass Reinforced	40 °C 60000 Hrs	0.255 A	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	13.2 VDC	Tubeaxial	86.18 g	0.19 lb	6850 RPM	0.924 mł/min	33 CFM	CE CSA UL VDE	Sintec	43 dB	25.4 mm	3.8 W	12 VDC	-20 ░C	70 °C	2 Wire Leads	60 mm	60 mm
ebm-papst Inc. 612NGMI	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	12.6 VDC	Tubeaxial	66.22 g	0.146 lb	4100 RPM	0.577 mł/min	20.6 CFM	CE CSA UL VDE	Sintec	31 dB(A)	25.4 mm	1.7 W	12 VDC	-20 ░C	65 °C	2 Wire Leads	60 mm	60 mm	(-20 ~ 65°C)
ebm-papst Inc. 612NGLE	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	66.22 g	0.146 lb	2500 RPM	0.314 m³/min	11.2 CFM	CE CSA UL VDE	Sintec	27 dB(A)	25.4 mm	0.58 W	12 VDC			2 Wire Leads	60 mm	60 mm		-20 °C	-4 °F	185 °F	85 °C
ebm-papst Inc. 612NH	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	84.82 g	0.187 lb	5600 RPM	0.759 m³/min	27.1 CFM	CE CSA UL VDE	Ball	37 dB	25.4 mm	2 W	12 VDC	-20 ░C	70 °C	2 Wire Leads	60 mm	60 mm
ebm-papst Inc. 612NMLE	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	66.22 g	0.146 lb	3000 RPM	0.412 mł/min	14.7 CFM	CE CSA UL VDE	Ball	19 dB(A)	25.4 mm	0.4 W	12 VDC			2 Wire Leads	60 mm	60 mm		-20 °C	-4 °F	185 °F	85 °C
ebm-papst Inc. 612N/2ML	Polyamide (PA) Nylon Fiberglass Reinforced			Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	86.18 g	0.19 lb		0.392 m³/min	14 CFM		Ball	35 dB	25.4 mm	0.8 W	12 VDC			3 Wire Leads	60 mm	60 mm						70 °C	70 °C	Speed Sensor (Tach)
ebm-papst Inc. 612NGH	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs	0.2 A	Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial			5600 RPM	0.708 m³/min	25.3 CFM	CE CSA EAC UL VDE	Sintec	35 dB	25.4 mm	2.4 W	12 VDC	-20 ░C	70 °C	2 Wire Leads	60 mm	60 mm								Auto Restart Locked Rotor Protection	0.363 in H2O	90.5 Pa
ebm-papst Inc. 612NGMLE	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	66.22 g	0.146 lb	3000 RPM	0.412 mł/min	14.7 CFM	CE CSA UL VDE	Sintec	16 dB	25.4 mm	700 mW	12 VDC	-20 ░C	80 °C	2 Wire Leads	60 mm	60 mm
ebm-papst Inc. 612N/2H	Polyamide (PA) Nylon Fiberglass Reinforced	70000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	66.22 g	0.146 lb	5600 RPM	0.708 m³/min	25.3 CFM	CE CSA UL VDE	Ball	19 dB(A)	25.4 mm	1.8 W	12 VDC	-20 ░C	70 °C	3 Wire Leads	60 mm	60 mm								Speed Sensor (Tach)
ebm-papst Inc. 612NGME	Polyamide (PA) Nylon Fiberglass Reinforced	80000 Hrs		Fiberglass Reinforced Polybutylene Terephthalate (PBT)	8 V	15 V	Tubeaxial	66.22 g	0.146 lb	4100 RPM	0.577 mł/min	20.6 CFM	CE CSA UL VDE	Sintec	27 dB(A)	25.4 mm	1.2 W	12 VDC	-4 °F	167 °F	2 Wire Leads	60 mm	60 mm
