1744109 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 9POS 3.96MM
| Part | Number of Positions | Voltage Rating | Mounting Type | Contact Length - Mating | Contact Length - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Overall Contact Length | Overall Contact Length | Applications | Contact Finish - Post | Number of Rows | Connector Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Length - Post | Contact Length - Post | Termination | Fastening Type | Material Flammability Rating | Shrouding | Insulation Color | Contact Material | Contact Shape | Style | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Insulation Material | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 9 | 250 VAC | Through Hole | 7.7 mm | 0.303 in | 1 µm | 39.4 µin | 14.4 mm | 0.567 " | General Purpose Industrial Lighting | Tin | 1 | Header | 1 çm | 39.4 çin | Male Pin | -25 °C | 105 ░C | 0.145 in | 3.68 mm | Solder | Locking Ramp | UL94 V-0 | Shrouded - 1 Wall | Blue | Brass | Square | Board to Cable/Wire | 7.5 A | 0.156 in | 3.96 mm | Polybutylene Terephthalate (PBT) | 8 |
